HAWKEYE9010 AXI
PRODUCT DESCRIPTION
It is a revolutionary automated X-ray inspection system that has built-in image analysis software and automatically determines the goodness and badness of the inspection sample using the image acquired by the inspection equipment itself. It is optimized for industry and precision parts inspection of mass production system structure requiring full inspection. The 2.5D system is a principle that examines acquired images after shooting at various angles and orientations. The AXI 2.5D system is an automated in-line inspection system designed for high-speed inspection in SMT. It is best solution for the in-line inspection of double-sided PCB parts.
features
- Provides fast scan speed (0.43~0.7sec/point)
- Upgrade inspection method (2D → 2.5D)
- Precision part / Electric & electronics parts / etc.
- Ability to analyze nested X-ray image
- Optimized for double-sided mounting board
specifications
Tube Voltage
110kV / 130kV
Focal Spot
7um
Inspection Area
-
Dimension (mm) (W x D x H)
1,050 X 1,610 X 1,403
1,500 X 2,150 X 1,600
Weight
1,000kg / 1,700kg
